Tool Servers
Tool Servers lists your tool servers and their agent URLs. Use the search bar to filter tool servers by name.
- Name—the user-defined name of the tool server.
- MCP Servers—icons representing the MCP servers your agent is connected to through the tool server.
- Agent URL—the endpoint URL your agents connect to, generated automatically when you create the tool server. Click the copy icon to copy the endpoint into your AI client.
You must have a system role of Administrator or Workspace Administrator to add, modify, or delete a tool server. Other users can view tool servers and connect to their own upstream accounts.
Add a Tool Server
1
Click + Add Tool Server. An Add Tool Server dialog appears.
2
In Step 1: Details, enter a Name for your tool server. Names must use lowercase letters, numbers, hyphens, and dots only. Click Next.
3
In Step 2: Select MCP Servers, add the MCP servers to bundle in this tool server.The left pane summarizes the servers in this tool server: the number of CData Source MCPs selected and a list of any third party MCP servers added. The right pane is the browse and configuration area.Click + Add MCP Server and choose one of the following:To add CData Source MCP servers: Click Add CData Source. In the right pane, browse or search for the data source MCPs available in your Connect AI workspace. Select the checkbox next to each source you want to include. Each entry shows the tool prefix applied to that source’s tools (for example, mailchimp2_*). The left pane updates to show the number of selected sources.To add third party MCP servers: Click Add Third Party Source. An entry form appears on the right. Enter the following information:
- Name—a name for this MCP server. The name is used as a prefix on this server’s tool names to keep them distinct.
- Upstream MCP URL—the endpoint of the upstream MCP server. Must be an HTTPS endpoint serving MCP over HTTP+SSE or Streamable HTTP.
-
Authentication—select the authentication type and follow the relevant instructions below.
When the Upstream MCP URL is the MCP host of your own Connect AI deployment, Authentication is automatically set to Connect identity (pass-through) and cannot be changed. Connect AI reuses the identity of the user calling the tool server, so no token or OAuth sign-in is required.
- OAuth 2.0 - Client Credentials
- Per-user OAuth
4
When you are finished adding MCP servers, click Save. The new tool server appears in the Tool Servers list with an automatically generated Agent URL.
